Magswitch Cobot MagBase 5 is intended for use with collaborative robotic arms and is UR+ certified. Designed specifically for the UR3 and UR5 robots, the Cobot magnetic base firmly fixtures 5 kg payload collaborative robots on ferrous materials with a twist of the wrist.

Magswitch pivoting arrays can be anchored to flat and cylindrical surfaces and feature a wide footprint to reduce the risk of peeling when the end effector is at its greatest radius. The array pivot points contain electrically isolating bushings and washers to ensure welding and static transient voltages on the part/substrate are decoupled from the robot ground.

Refer to the dimensional drawing below for the default mounting pattern. Custom patterns can be incorporated upon request.

Downloads

Cobot Magbase 5 Downloads:

• 81001276 Cobot MagBase 5 Spec Sheet
• 81001276 Cobot MagBase 5 STEP File

Magswitch Downloads:

• Automation Catalog
• MAC Declaration of Incorporation – Assembly Manual ( English | Spanish | German | French)
